Brake pads P6000102AA, JZ20/1580Z shipped to Kazakhstan

A drilling winch is one of the important equipment to the drilling rig for oil and gas drilling, and the brake pad is an important wear part for the drilling winch, and its service life largely affects the operation of the drilling winch. KINGWELL brake pads are made of high-quality friction materials and advanced production technologies, and their service life is not inferior to domestic and foreign analogs. This time, we provide customers with brake pads P6000102AA, JZ20/1580Z, which are used for the XJ650 drilling rig.

Detailed parameters for JZ20/1580Z brake pads (winch pad for drilling rig)
Code: P6000102AA
Length - 304mm, six holes for mounting bolts,
Horizontal distance between bolt holes - 226mm,
Distance from the wall to the hole - 39mm,
Diameter of the inlet hole - 11mm, outlet - 21mm.
Pad thickness - 26mm
Vertical distance between the extreme holes - 171mm, distance between the extreme and middle hole - 85.5mm.
In addition to each pad, it is necessary to supply copper bolts with nuts in the quantity of 6 pieces each.

In addition to the above-mentioned brake pads, KINGWELL company can also provide the following:
1.) Brake pads with brakes JC21A, JC28/11, JC28A, P4300011AA, P6000102AA, P6000551AA, etc.
2.) Disc brake pads PZ30-02-15, PZ40-01-05, PSZ6***, PSZ7***, PS80-06, etc.
